Wilcoxon - PCC420VR-10-R6: Compact Velocity Sensor (RMS, 1.0 ips)

Wilcoxon

Top exit, compact, 105°C, 4-20 mA (±5% @ full scale) proportional to
acceleration or velocity; peak or rms, 1/4-28 mounting hole (stud included),
MIL-C-5015 connector

$210.00 USD

1

The W5 Engineering Advantage

Icon for award

20+ Years in Testing

Icon for users

All Across North America

Icon for trust

Trusted by Industry Leaders

Icon for clock

24-Hour Engineering Replies

Icon for users

Secure Order Processing

Icon for Award

ISO-Level Quality Assurance

Compact vibration transmitter, velocity, RMS, 1.0 in/sec

Vibration transmitter, 4-20 mA output proportional to RMS velocity, 1.0 in/sec full-scale measurement range, operation to 105°C, top exit 2-pin MIL-C-5015-style connector, the upgraded PCC42X series is smaller, lighter and lower price

Vibration transmitter sensors represent vibration levels by a loop current of 4-20 mA, which can be easily integrated into existing plant control systems, such as a PLC, DCS, or SCADA system. As part of a continuous monitoring setup, 4-20 mA trend data can be easily compared against standard vibration guides to indicate general machine health.

Vibration transmitter features

  • RMS output, velocity
  • 1.0 ips (25.4 mm/sec) full scale range
  • Easily integrated into existing process control systems
  • More compact housing than legacy 4-20mA sensors

Included accessories

  • SF6 mounting stud

Specifications

Sensor output 4-20 mA
Measurement unit Velocity
Detector type RMS
Full-scale range 1.0 IPS
Frequency response, ±3 dB 3.5 Hz - 2,000 Hz
Connector style MIL-C-5015, 2-pin
Connector orientation Top exit
Temperature range -40°C to +105°C
Weight 120 grams
Hazardous area approvals Non-approved
